Notes on Usage

Environmental Limits

1. Use Control Terminal at an ambient temperature

of 0 to 50ºC, and a relative humidity of 35 to 85

%RH. (But, a ZM-72D/T STN multi-color display

can be used at 0 to 40ºC.)

2. Install a forced fan or an air conditioner to

maintain the ambient temperature when it is

higher than the above mentioned range.

3. Avoid places where moisture may easily

condense due to sudden temperature changes.

4. Avoid direct sunlight.

0∼50℃

YOUZAI

Fan

Vent

5. Never install Control Terminal in a place where

impacts or vibrations may be transmitted.

6. Avoid any place in which there is the possibility

that water, corrosive gas, flammable gas,

solvents or coolants, grinding oil can come in

contact with the unit. Never install the unit in a

place where dust, salt and metallic particles are

present.

Locations

1. Secure sufficient space around Control Terminal

for ventilation.

2. Never attach Control Terminal to the top of any

apparatus generating high levels of heat (heater,

transformer, large-capacity resistor, etc.).

1 Notes on Usage
