Available Memory

Memory

Bit Write TYPE Remarks

D (data register) 0

R (link register) 1

B (file register) 2

N (current value register) 3

X (input relay) 4 WX as word device

Y (output relay) 5 WY as word device

M (internal relay) 6 WM as word device

K (keep relay) 7 WK as word device

L (link relay) 8 WL as word device

T (counter/contact) 9 WT as word device

C (counter/contact) 10 WC as word device

U (expansion data register) 11

H (expansion set value register) 12

EN (expansion current value) 13

EX (expansion input) 14 WEX as word device

EY (expansion output) 15 WEY as word device

EM (expanion internal relay) 16 WEM as word device

EK (expansion latched relay) 17 WEK as word device

EL (expansion link relay) 18 WEC as word device

ET (expansion timer [contact]) 19 WET as word device

EC (expansion counter [contact]) 20 WEC as word device

V (special register) 19 WV as word device

2 TOYOPUC PC

Set the memory to the extent of the memory range of each PC model. In case of using the

[Bit Write] memory as the bit device of the [Output Action] is [Momentary W], the other

bits will be cleared when the bit memory is output, because the [Bit Write] will be output

by one word (refer to P5-10, reference 14-7 of ZM-71SE Instruction Manual). Use [TYPE]

number to assign indirect memory for macro programs.

Available: Unavailable:

1 2 ... 126 127 128 129 130 131 132 133 134 135 136 ... 200 201
