Installation
Please attach ZM-43SM/80SM in ZM-43/52/72/82 in the following procedure.
1. The battery (CR2430) of an attached article is turned to the socket of ZM-43SM/80SM, "+" side is turned
upwards, and it sets. In case it sets, as a battery is pushed in a plug and the direction of "+" side, "-" side
also inserts it in "+" side.
2. The date of five years after is entered in the "next battery exchange day" column of the cautions seal of an
attached article, and as shown in the following figure, it sticks on it.
- The term of validity of the battery of ZM-43SM/80SM is about five years at 25 degrees. Even if it
was less than five years, when the voltage of a battery falls, the 4th bit of the internal memory
(address #s167) of ZM-43/52/72/82 turns ON, and it warns of battery exchange. Please exchange
batteries quickly.
3. The power supply of ZM-43/52/72/82 is turned OFF.
4. The cover of an expansion memory cassette part is removed and ZM-43SM/80SM is attached.
Setting of ZM main body
In screen edit software ZM-71SE, [SRAM cassette setup (W)] of a [System setup(A)] is chosen, and [SRAM
cassette setting] dialog is set up. When you change a setup, please be sure to format.
The following procedure performs adjustment and a format of the date of ZM-43SM/80SM, and time.
1. The [local main] screen of ZM-43 main part is displayed.
2. The "cassette adjustment" switch of a [local main] screen is pushed.
3. A [cassette adjustment] screen is displayed. Adjustment and a format of a date and time are performed here.
