Operation of ZM-
**
Main Menu
16
"Main Menu" after trasferring dataWhen power is turned ON for the first time:
Main Menu
Main Menu
System Information
System Information
Screen Data
Information
Screen Data
Information
Size :
Size :
PLC Type:
Comment:
Error: Stop
Time-Out: 0.50 sec
Retry: 3
Connection: 1 : 1 Baud Rate: 19200
Signal Level: RS232C Data Length: 7
PLC Stat.No.: 0 Stop Bit: 1
Parity: Even
Send Delay: 0msec
SYSTEM PROG. VER.1.000
FONT
VER.1.000/1.000/1.000
JAPANESE 32
I/F DRV VER. 1.000
1998- 9- 1 07 : 23 : 30
Editor : MJ1
Memory-Card
I/O Test
ZM-72T
786432
When the power of ZM-
**
is turned ON for the first time, the screen on the below left is displayed. After
transferring the screen data to ZM-
**
, the following "Main Menu" is displayed.
S
Y
S
T
E
M
M
O
D
E
the [SYSTEM] switch the [F1] switch
The "Main Menu" is displayed.
S
Y
S
T
E
M
M
O
D
E
Main Menu
Main Menu
System Information
System Information
Screen Data
Information
Screen Data
Information
Size :
Size :
PLC Type:
Comment:
Error: Stop
Time-Out: 0.50 sec
Retry: 3
Connection: 1 : 1 Baud Rate: 19200
Signal Level: RS232C Data Length: 7
PLC Stat.No.: 0 Stop Bit: 1
Parity: Even
Send Delay: 0msec
SYSTEM PROG. VER.1.000
FONT
VER.1.000/1.000/1.000
JAPANESE 32
I/F DRV VER. 1.000
1998- 9- 1 07 : 23 : 30
Editor : MJ1
Memory-Card
I/O Test
ZM-72T
786432
If the screen data has been already transferred to ZM-
**
, press the [SYSTEM] switch, then press the [F1]
switch. The [Main Menu] is displayed.
Main Menu
The "Main Menu" is the system menu for transferring the data between a personal computer and ZM-
**
.
When the screen data is transferred from a personal computer to ZM-
**
, the "Main Menu" must be displayed.
(If [Editor port] is selected for [Modular Jack 1] in the [P2] menu of the editing software or the on-line editing is
executed, it is not necessary to display the "Main Menu".
