2 - 68

Available Memory

Memory Bit Write TYPE Remarks

R (data register) 0

I (input relay) 1

Q (output relay) 2

M (internal relay) 3

S (stage) 4

GI (global inputs) 5

GQ (global outputs) 6

T (timer/contact) 7

C (counter/contact) 8

Memory Bit Write TYPE Remarks

D (data register) 0

X (input relay) 1 X/Y common use

Y (output relay) 2 X/Y common use

M (internal relay) 3

S (stage) 4

K (keep relay) 5

L (link relay) 6

T (timer/contact) 7

C (counter/contact) 8

SR-1T/6T (TOYOTA version)

SU/SG

2 Koyo PC

Available: Unavailable:

Set the memory to the extent of the memory range of each PC model. In case of using the

[Bit Write] memory as the bit device of the [Output Action] is [Momentary W], the other

bits will be cleared when the bit memory is output, because the [Bit Write] will be output

by one word (refer to P5-10, reference 14-7 of ZM-71SE Instruction Manual). Use [TYPE]

number to assign indirect memory for macro programs.

Available: Unavailable:
