Appendix. C Pin Assignment Appendices
Satellite A50S/TECRA A3X Maintenance Manual (960-534) [CONFIDENTIAL] C-25
C.24 CN8020 1st Battery Connector (10-pin)
Table C-24 1st Battery connector pin assignment (10-pin)
Pin No. Signal name I/O Pin No. Signal Name I/O
1 CHGVL O 2 BTMP1 O
3 DCHG I 4 M5V I
5 PSCL-S5P O 6 PSDA-S5P O
7 GND - 8 DBT10V-S5N O
9 GND - 10 GND -
C.25 CN9990 RTC Battery Connector (3-pin)
Table C-25 RTC Battery connector pin assignment (3-pin)
Pin No. Signal name I/O Pin No. Signal Name I/O
1 R3V O 2 N.C. -
3 GND -
C.26 CN8770 FAN I/F Connector (4-pin)
Table C-26 FAN I/F connector pin assignment (4-pin)
Pin No. Signal name I/O Pin No. Signal Name I/O
1 P5V I 2 GND -
3 FANG0-P3P O 4 FPWM0-S3P I
