3.31 SETUP 3 Tests and Diagnostics
3-90 [CONFIDENTIAL] Satellite A50S/TECRA A3X Maintenance Manual (960-534)
CAUTION: Sound (Legacy) test is not supported in this model.
3.31 SETUP
3.31.1 Function Description
This program displays the current system setup information as listed below:
1. Memory
2. System Date/Time
3. Battery
(a) Battery Save Mode
(b) PCI Express Link ASPM
4. Password
5. HDD Password
(a) HDD
(b) HDD Password Mode
(c) User Password
(d) Master Password
6. Boot Priority
(a) Boot Priority
(b) HDD Priority
(c) Network Boot Protocol
7. Display
(a) Power On Display
(b) LCD Display Stretch
(c) TV Type
8. Others
(a) Dynamic CPU Frequency Mode
(b) Execute-Disable Bit Capability
(c) Auto Power On
(d) Diagnostic Mode
(e) Language During Bootup
9. Configuration
