3 Tests and Diagnostics 3.20 ONLY ONE TEST
Satellite A50S/TECRA A3X Maintenance Manual (960-534) [CONFIDENTIAL] 3-41
3.20 ONLY ONE TEST
3.20.1 Program Description
This program tests the unique functions of this model.
3.20.2 Operations
Select test 2 from the DIAGNOSTIC MENU and press Enter. The following menu appears in the
display.
#################################################################
######## ONLY ONE TEST Menu (XXXXXXXXX) #######
#################################################################
* *
* 1 ............ Pressed Key Display *
* 2 ............ Touch Pad *
* 3 ............ GP Button *
* 4 ............ Kill Switch *
* 5 ............ USB *
* 6 ............ Docker Dock/Undock *
* 7 ............ LED *
* *
* 9 ............ Exit to Common Test *
* *
*****************************************************************
.... Press test number [1-7, 9]?
Select the subtest number you want to test and press Enter.
To return to the DIAGNOSTIC TEST menu, select 9 and press Enter.
