Appendices Appendix. B Board Layout
B-2 [CONFIDENTIAL] Satellite A50S/TECRA A3X Maintenance Manual (960-534)
Table B-1 System board ICs and connectors (front)
Mark Number Name
(a) CN8770 Fan cable I/F connector
(b) CN5000 LCD harness connector
(c) CN3280 Membrane SW I/F connector
(d) PJ3502 FLGCP*/FLGSR* I/F connector
(e) CN3240 Touch pad connector
(f) CN3200 Keybaord connector
(g) CN3290 Debuging port connector
(h) IC1600 ICH6-M
(i) CN6002 Speaker(R) cable connector
(j) CN6001 Speaker(L) cable connector
(k) CN9500 FLGSN* I/F connector
(l) CN1800 HDD I/F connector
(m) IS2110 PC card I/F connector
(n) IC2000 Card Controller
