4.13 Parallel port board / Serial port board / S-Video board 4 Replacement Procedures
Satellite A50S/TECRA A3X Maintenance Manual (960-534) [CONFIDENTIAL] 4-39
4.13 Parallel port board / Serial port board / S-Video board
Depending on the model, the machine has a different type board (Parallel port board / Serial
port board / S-Video board). Refer to the proper procedures below.
4.13.1 Parallel port board
Removing the Parallel port board
The following describes the procedure for removing the Parallel port board (See Figure 4-27,
4-28).
1. Remove the DC-IN jack and core from the slot of the base assembly.
2. Remove the following screws to remove the harness holder.
? M2.5x4B THIN BIND screw x2
Figure 4-27 Removing Harness Holder
DC
-
IN Jack
Harness Holder
M2.5x4B
THIN BIND
