4.20 LCD Unit/FL Inverter 4 Replacement Procedures
Satellite A50S/TECRA A3X Maintenance Manual (960-534) [CONFIDENTIAL] 4-59
8. Remove the following screws securing the LCD brackets. Remove the LCD
brackets from the LCD module.
? M2x3 SUPER THIN BIND screw x4
Figure 4-42 Removing LCD Bracket
M2x3C SUPER THIN BIND
LCD Bracket
M2x3C SUPER THIN BIND
