1.8 DVD Super Multi drive 1 Hardware Overview

Satellite A50S/TECRA A3X Maintenance Manual (960-534) [CONFIDENTIAL] 1-21

1.8 DVD Super Multi drive

The DVD Multi drive accommodates either 12 cm (4.72-inch) or 8 cm (3.15-inch) CD, CD-

R/RW and DVD. It is a high-performance drive that reads CD at maximum 24-speed (3,600

KB per second) and writes DVD-RW at 2-speed, DVD-RAM at 2-speed, DVD-R at4-speed,

DVD+R at 2.4-speed and DVD+RW at 2.4-speed.

The DVD Super Multi drive is shown in Figure 1-9. The specifications of the DVD Super

Multi drive are described in Table 1-10 and 1-11.

Figure 1-9 DVD Super Multi drive

Table 1-10 DVD Super Multi drive dimensions

Items Standards

Maker

Panasonic

(G8CC0002T220)

TEAC

(G8CC0002S220)

Dimensions

Width (mm)

128

Height (mm)

12.7

Depth (mm)

129.0 129.4

Weight (g)

190 ±10

190 (max)
