Appendix. B Board Layout Appendices
Satellite A50S/TECRA A3X Maintenance Manual (960-534) [CONFIDENTIAL] B-5
B.3 Sound Board (FLGSN*)
(Front)
(Back)
Figure B-3 Sound Board (FLGSN*) layout
Table B-3 Sound Board (FLGSN*) connectors
Mark Number Name
(a) CN9510 System board I/F connector
(b) J6310 Headphone connector
(c) J6070 External microphone connector
(a)
(b)
(c)
