7-70
SYSTEM SETTINGS
Contents
Interface Settings
These settings are used to control and monitor data transmitted to the USB port or network port of the machine.
Hexadecimal Dump Mode
This function is used to print the print data from a
computer in hexadecimal format together with the
corresponding ASCII text. This allows you to check
whether or not print data from the computer is being
transmitted to the machine correctly.
Example of a hexadecimal dump
I/O Timeout
The I/O timeout can be set to any number of seconds
from 1 to 999.
The I/O timeout function temporarily breaks the
connection if the set duration of time elapses without any
data being received by the port. After the connection is
broken, the port is set to auto selection or the next print
job is begun.
Enable USB Port
This is used to enable printing from the USB port.
USB Port Emulation Switching
If the machine is connected using the USB port, select
the emulated printer language.
The settings are shown below.
•Auto
• PostScript
•PCL
Enable Network Port
This is used to enable printing from the network port.
Network Port Emulation Switching
This setting is used to select the emulated printer
language when the machine is connected by a network
port.
The settings are shown below.
•Auto
• PostScript
•PCL
Port Switching Method
This setting is used to select when port switching takes
place.
Switch at End of Job
The port changes to auto selection when printing ends.
Switch after I/O Timeout
When the time set in "I/O Timeout" elapses, the port
changes to auto selection.
• The settings are the same as those of "Network Port
Emulation Switching".
• Unless printer errors occur frequently, it is
recommended that you use the factory default
setting "Auto".
• The settings are the same as those of "USB Port
Emulation Switching".
• Unless printer errors occur frequently, it is
recommended that you use the factory default
setting "Auto".
The following two print ports are available on the
machine:
• USB port
• Network port
