51
REPLACING SUPPLIES AND MAINTENANCE
3
Clean the PT charger.
(1) Slowly pull the PT charger cleaner out until you feel a
slight resistance.
(2) Slowly push the PT charger cleaner back in.
(3) Repeat the above (1) to (2) three times.
4
Install the toner collection container.
☞ Replacing the toner collection container (page 15)
(1)
(2)
