2-53
COPIER
Contents
COPYING TWO ORIGINAL PAGES ONTO
ONE SHEET (2in1)
Two original pages can be copied onto one sheet of paper. This function is convenient when you wish to present
multiple pages in a compact format, or show a view of all pages in a document.
By copying two originals onto one sheet, the amount of paper used can be cut in half.
1
Place the original.
Place the original face up in the document feeder tray, or face down on the document glass.
When using this function with a portrait original on the document glass, place the original so that the top of the image is to the
right.
After placing the original, specify the original size.
☞ ORIGINAL SIZES (page 2-29)
2
Select the special modes.
(1) Touch the [Special Modes] key.
(2) Touch the [2in1] key.
☞ Special modes menu (1st screen) (page 2-40)
B
A
A B
abc
Top of image to
the right
