26
INSTALLING THE PRINTER DRIVER / PC-FAX DRIVER
When installing the PCL5c printer driver, PS printer driver, PPD driver, or
PC-Fax driver
Installation is possible even after the USB cable has been connected. When the
software selection screen appears in step 6 of "OPENING THE SOFTWARE
SELECTION SCREEN (FOR ALL SOFTWARE)" (page 8), perform the steps
below.
1
Click the [Printer Driver] button.
To install the PC-Fax driver, click the [PC-Fax Driver] button on the "Disc 2"
CD-ROM.
*The above screen appears when using the "Disc 1" CD-ROM.
2
Click the [Custom installation] button.
!mxc381_us_ins.book 26 ページ ２００８年８月１９日 火曜日 午前１０時４２分
