2-85
COPIER
Contents
WHITENING FAINT COLORS IN COPIES (Suppress
Background)
This feature is used to suppress light background areas.
1
Place the original.
Place the original face up in the document feeder tray, or face down on the document glass.
After placing the original, specify the original size.
☞ ORIGINAL SIZES (page 2-29)
2
Select the special modes.
(1) Touch the [Special Modes] key.
(2) Touch the [Color Adjustments] key.
(3) Touch the [Suppress Background] key.
☞ [Color Adjustments] KEY (page 2-82)
3
Select the suppress background setting.
(1) Adjust the background suppression level.
Touch the [+] key to suppress only faint background.
Touch the [-] key to suppress faint to dark background.
(2) Touch the [OK] key.
You will return to the special modes screen. Touch the
[OK] key to return to the base screen of copy mode.
Light areas are
suppressed.
Level [+]
Level [-]
The lightness level at which
suppression takes place
can be adjusted.
OK
OK
Cancel
Color Adjustments
Suppress Background
Light areas of the original may be suppressed as background.
31
(1) (2)
