2-19
COPIER
Contents
3
Specify the original size.
(1) Touch the appropriate original size key.
(2) Touch the [OK] key.
When placing an AB size or non-standard size original, specify the original size as explained in "ORIGINAL SIZES"
(page 2-29).
4
Touch the [2-Sided Copy] key.
5
Select the 2-sided copy mode.
(1) Touch the [1-Sided to 2-Sided] key.
(2) Touch the [OK] key.
The [2-Sided to 2-Sided] key and [2-Sided to 1-Sided] key cannot be used when copying from the document glass.
5½x8½
8½x13
8½x11
8½x14
8½x13
Custom Size None
Original
OK
Size Input
Inch
AB
2
5
(2)(1)
8½x11
8½x11
5½x8½
Auto
8½x11
Plain
8½x14
8½x11
8½x11
Color Mode
Special Modes
Plain
2-Sided Copy
Output
File
Quick File
Copy Ratio
100%
3.
2.
1.
Original
Paper Select
Full Color
Exposure
Auto
4.
OK
2-Sided Copy
Binding
Change
(1) (2)
