41
REPLACING SUPPLIES AND MAINTENANCE
3
To clean the removed rollers, wipe each roller with
a clean cloth.
Caution
When cleaning the rollers, be careful not to injure your hands.
Do not touch the surface of the roller if your hands are dirty.
• If the dirt is difficult to remove, moisten the cloth with water or a
neutral detergent. After wiping, wipe the roller dry with a clean cloth
and go to the step 10.
• When you replace roller, go to the next step.
4
Close the document conveyor cover on the
automatic document feeder.
Take care that your fingers are not pinched when closing the cover.
