5. PARAMETERS

5 - 40

No. Symbol Name and function

Initial

value

(unit)

Setting

range

PD08



DO2

Output device selection 2

You can assign any output device to the CN3-9 pin. INP (In-position) is assigned in the initial

setting.

The devices that can be assigned and the setting method are the same as in [Pr. PD07].

Refer to Name

and function

column.

Setting

digit

Explanation

Initial

value

_ _ x x Device selection

Refer to table 5.8 in [Pr. PD07] for settings.

04h

_ x _ _ For manufacturer setting 0h

X _ _ _ 0h

PD09



DO3

Output device selection 3

You can assign any output device to the CN3-15 pin. ALM (Malfunction) is assigned in the

initial setting.

The devices that can be assigned and the setting method are the same as in [Pr. PD07].

Refer to Name

and function

column.

Setting

digit

Explanation

Initial

value

_ _ x x Device selection

Refer to table 5.8 in [Pr. PD07] for settings.

03h

_ x _ _ For manufacturer setting 0h

x _ _ _ 0h

PD12



DOP1

Function selection D-1

Refer to Name

and function

column.

Setting

digit

Explanation

Initial

value

_ _ _ x For manufacturer setting 0h

_ _ x _ 0h

_ x _ _ 0h

x _ _ _ Servo motor thermistor enabled/disabled selection

0: Enabled

1: Disabled

For servo motors without thermistor, the setting will be disabled.
