5-81
SCANNER/INTERNET FAX
Contents
WHITENING FAINT COLORS IN THE IMAGE
(Suppress Background)
This feature is used to suppress light background areas.
• This function cannot be used in Internet fax mode.
• When using USB memory mode, connect the USB memory device to the machine before performing the procedure below.
1
Place the original.
Place the original face up in the document feeder tray, or face down on the document glass.
When the original is a different size than the size setting, set the original size.
☞ SPECIFYING THE ORIGINAL SCAN SIZE AND SEND SIZE (page 5-51)
2
Specify the destination.
☞
ENTERING DESTINATIONS (page 5-17)
When scanning to USB memory, there is no need to specify the destination. Go to step 3.
3
Select the special modes.
(1) Touch the tab of the mode that you wish to use.
(2) Touch the [Special Modes] key.
(3) Touch the [Suppress Background] key.
Read the message that appears and then touch the [OK] key.
☞ SPECIAL MODES (page 5-65)
The lightness level at which
suppression takes place
can be adjusted.
Level [+]
Level [-]
