REPLACING SUPPLIES AND MAINTENANCE
9
Install the toner collection container.
☞ Replacing the toner collection container (page 15)
10
Close the front cover.
Take care that your fingers are not pinched when closing the cover.
11
Turn on the power.
Switch the main power switch "ON" and press the [POWER] key ( ) on the
operation panel to turn on the operation panel power.
(1)
(2)
