8-144
Default Setting (System Menu)
5 Press the U or V key to select [Secure Protocol].
6 Press the OK key. Secure Protocol appears.
7 Press the U or V key to select [POP3 Security 1],
[POP3 Security 2] or [POP3 Security 3].
If you selected POP3 Security 1, follow the procedure
below. If you selected POP3 Security 2 or POP3 Security
3, set in the same way.
8 Press the OK key. POP3 Security 1 appears.
9 Press the U or V key to select [Off], [SSL/TLS] or
[STARTTLS].
10 Press the OK key. Completed. is displayed and the
screen returns to the Secure Protocol menu.
SNMPv3 Setting
Sets up SNMPv3. The default setting is Off. Use the procedure below.
Refer to Protocol Detail on page 8-132 about the procedures.
Secure Protocol:
a
b
4
LDAP Security
5
SMTP Security
*********************
[ Exit ]
6
POP3 Security 1
POP3 Security 1:
a
b
*********************
2
SSL/TLS
3
STARTTLS
1
*Off
