8-134
Default Setting (System Menu)
8 Press the OK key. The Protocol Detail menu appears.
9 Press the U or V key to select the item for which you
want to make settings.
10 Press the OK key. This displays the setting screen for
the item selected in step 9.
The screen shown is the one when [FTP(Client)] is
selected.
11 Press the U or V key to select [On] or [Off].
If you select [On] for each of [FTP(Client)] and [IPP] and
press the OK key, a port number entry screen appears.
Press the U or V key or the numeric keys to set the port
number.
12 Press the OK key. Completed. is displayed and the
screen returns to the Protocol Detail menu.
Protocol Detail:
a
b
*********************
2
SNMPv3
3
FTP(Server)
1
NetBEUI
FTP(Client)
:
a
b
1
Off
*********************
2
*On
Port Number
:
D
b
(1 - 65535)
******631*
