Sharp MX-2301N Specifikace stáhnout pdf

Shown with options.

670 mm

1,210 mm

620 mm

SHARP CORPORATION OF AUSTRALIA PTY LTD

ABN 40 003 039 405

1 Huntingwood Drive, Huntingwood NSW 2148

P.O. Box 6827, Blacktown, NSW 2148

Tel: (02) 9830 4600 Fax: (02) 9672 1208

www.sharp.net.au

©SHARP CORP. Printed in Australia

SHARP CORPORATION OF NEW ZEALAND LTD

59 Hugo Johnston Drive

P.O. Box 12244, Penrose, Auckland

Tel: (09) 573 0111 Fax: (09) 573 0112

www.sharp.net.nz

Distributed by:

SPECIFICATIONS

Make the Move to Colour,

the Jump to Added Performance

Desktop

Max. 23 cpm/ppm (A4, long-edge feeding)

Max. A3 wide, min. A5R

Standard: 1,100 sheets

(two 500-sheet trays and 100-sheet multi-bypass tray)

Maximum: 2,100 sheets

Tray: 60 g/m

to 209 g/m

Multi-bypass tray: 55 g/m

to 256 g/m

Less than 60 sec.

Copier memory: 1GB

Printer memory: 512MB

80GB HDD*

230 - 240V AC, 50/60 Hz

1.84 kW

620 x 670 x 950 mm

Approx. 112 kg

Card shot, edge/centre erase, job build, document filing,

user authentication (1,000 accounts),

pre-heat/auto power shut-off modes

Original paper size

First copy time*

Continuous copy

Resolution

Gradation

Zoom range

Preset copy ratios

Features*

Max. A3

Full colour: 8.9 sec. B/W: 6.0 sec.

Max. 999 copies

Scan (colour): 600 x 600 dpi

Scan (B/W): 600 x 600 dpi, 600 x 400 dpi, 600 x 300 dpi

Print: 600 x 600 dpi

Equivalent to 256 levels

25 to 400% (25 to 200% using RSPF) in 1% increments

10 ratios (5R/5E)

Auto paper selection (mixed/random size feeding), auto magnification

selection, paper type selection, auto tray switching, rotation copy,

electronic sorting, network tandem copy, book copy, margin shift,

dual page copy, multi-shot (4-in-1, 2-in-1), cover/transparency/tab page

insertion, pamphlet copy, 2-sided copy orientation change, XY zoom,

B/W reverse, mirror image, duplex copy, reserved copy, job programme,

image repeat, irregular original/paper size input, stamps

(date, page number, text, stamp), multi-page enlargement, tab copy,

centering, proof copy, 3G Sharp auto colour mode, auto colour selection,

auto calibration

B/W Facsimile (optional MX-FXX2 required)

Compression method

Communication protocol

Transmission time

Modem speed

Transmission resolution

Recording width

Memory

Grey scale levels

Features

MH/MR/MMR/JBIG

Super G3/G3

Less than 3 seconds*

33,600 bps to 2,400 bps with automatic fallback

From Standard (203.2 x 97.8 dpi) to Super Fine (406.4 x 391 dpi)

A3 to A5

8MB flash memory

Equivalent to 256 levels

Duplex transmission/reception, quick on-line transmission,

error correction mode, 999 one-touch dials, 500 group dials,

LDAP support, 48 job programmes, broadcasting number registration,

F-Code compatibility (confidential, relay broadcast), polling,

memory transmission/reception, auto reduction (transmission/reception),

rotation transmission/reception, print actual size, 2-in-1 transmission,

long original transmission (max. 1,000 mm), PC-Fax transmission,

timer transmission, inbound routing to e-mail, activity report,

anti-junk fax, dual page scan, mixed size original scanning

Type

Engine speed (colour & B/W)

Paper size

Paper capacity

(80 g/m

)

Paper weight

Warm-up time*

Memory

Power requirements

Power consumption (max.)

Dimensions (W x D x H)

Weight

Features

General

Copier

Network Printer

Network Scanner

Scan method

Resolution

File formats

Scanner utility

Scan destinations

Features

Push scan (via control panel), pull scan (TWAIN-compliant application)

Push scan: 100, 200, 300, 400, 600 dpi

Pull scan: 75, 100, 150, 200, 300, 400, 600 dpi

50 to 9,600 dpi via user setting

TIFF, PDF, encrypted PDF, JPEG (colour only)

Sharpdesk

Scan to e-mail, desktop, FTP server, network folder (SMB), USB memory

Internet fax*

(supports direct SMTP), PC-Internet fax transmission*

3G Sharp auto colour mode, mixed size original scanning, LDAP support,

direct entry (address, subject, message), 999 one-touch dials,

500 group dials, 48 job programmes, broadcasting, long original

scanning (max. 1,000 mm)*

, auto colour selection

Resolution

Interface

Supported OS*

Network protocols*

Printing protocols

PDL (emulation)

Available fonts

Features*

600 x 600 dpi

USB 2.0

10Base-T/100Base-TX/1000Base-T

Windows Server

2003, Windows

XP, Windows Vista

®,

Windows

Mac OS 9.0 to 9.2.2, Mac OS X 10.2.8, 10.3.9, 10.4 to 10.4.11, 10.5 to

10.5.6,10.6

TCP/IP (IPv4, IPv6), IPX/SPX (NetWare), NetBEUI, EtherTalk (AppleTalk)

LPR, Raw TCP (port 9100), POP3 (e-mail printing), HTTP,

Novell Printserver application with NDS and Bindery,

FTP for downloading print files, EtherTalk printing, IPP

Standard: PCL 6 emulation

Option*

: PS3 emulation

80 fonts for PCL, 136 fonts for PS3 emulation

Network tandem print, RIP Once/Print Many, job retention (print hold,

proof print, confidential print), direct PDF/TIFF/JPEG printing,

carbon copy print, duplex print, font/form download, offset output,

printer administration utility and status monitor, pamphlet style,

IP/MAC address filtering, port/protocol management, binding edge,

N-up (2/4/6/8/9/16), paper/output tray selection, cover insertion,

transparency interleave, fit to page, watermarks, form overlay,

auto configuration, barcode font compatibility, tab print, poster print,

secure network communications (SSL and IPsec [LPD]), toner save mode

* 1 : At rated voltage, 23

C. May vary depending on operating conditions.

* 2 : HDD capacity depends on procurement and sourcing status.

* 3 : Long-edge feeding of A4 sheets from 1st paper tray, using document glass, without Auto

Colour Selection and Auto Colour mode, polygon motor running. May take longer when taking a copy for

the first time immediately after turning the machine on.

* 4 : Some features require option(s).

* 5 : Optional MX-FWX1 required.

* 6 : B/W documents only, scanned at under 400-dpi resolution. Max. 800 mm for Internet faxing or when

scanning at 600 x 600-dpi resolution.

* 7 : Measured using Sharp’s standard chart (A4 with 6% coverage, B/W). The Quick File Folder shares the

HDD with the Job Build function; up to 12GB of data storage is available when using both functions.

The storage capacity will be less for colour pages.

* 8 : Optional MX-PKX1 required for Mac OS, EtherTalk, and PS3.

* 9 : Print driver support will be available at a later date.

* 10 : Some features are not available according to the printer driver used.

* 11 : Based on Sharp’s standard chart with approx. 700 characters (A4 long-edge feeding) at

standard resolution in Super G3 mode, 33,600 bps, JBIG compression.

Document Filing

Document filing capacity

Stored jobs*

Storage folders

Confidential storage

Main and custom folders: 38GB, 5,500 pages*

or 3,000 files

Quick file folder: 12GB, 1,700 pages*

or 1,000 files

Copy, print, scan, fax transmission

Quick file folder, main folder, custom folder (max. 1,000 folders)

Password protection

Digital Full Colour Multifunctional System

MX-2301N

Digital Full Colour Multifunctional System

s$ESIGNANDSPECIFICATIONSARESUBJECTTOCHANGEWITHOUTPRIORNOTICE

s#OLOURVARIATIONSTOPRODUCTSMAYOCCURDUETOPRINTING

s3OMEFEATURESREQUIRE/PTIONALITEMS0LEASECONSULTWITHANAUTHORISED3HARP2ESELLERFORDETAILS

s!LLINFORMATIONANDTECHNICALDETAILSARECORRECTASATMACHINERELEASEDATE

s7INDOWS7INDOWS.47INDOWS3ERVERAND7INDOWS6ISTAAREREGISTEREDTRADEMARKSOF-ICROSOFT

Corporation in the United States and/or other countries. All other brand names and product names may be

trademarks or registered trademarks of their respective owners.

s4HE%NERGY3TARLOGOISACERTIFICATIONMARKANDMAYONLYBEUSEDTOCERTIFYPRODUCTSTHATHAVEBEEN

determined to meet the Energy Star programme requirements. Energy Star is a US registered mark.

The Energy Star guidelines apply to products only in the US, Europe, Australia, New Zealand, and Japan.

Copy

Network Print Network Scan Sharpdesk

Fax

OPTION

MX-2301N
