4-6
Copying Functions
Original Orientation
Select the original orientation to use the following functions.
•Duplex
• Combine mode
When placing originals on the platen
When placing originals on the document processor
NOTE: To change the default setting for the original orientation, refer to Function Defaults on page 8-43.
[Top Edge Top] [Top Edge Left]
[Top Edge Top]
[Top Edge Left]
