8-94
Default Setting (System Menu)
Font List
Check the font samples installed in the machine.
Use the procedure below to print a Menu Map / Status Page / Font List.
1 In the Sys. Menu/Count. menu, press the U or V key to
select [Report].
2 Press the OK key. The Report menu appears.
3 Press the U or V key to select [Report Print].
4 Press the OK key. The Report Print menu appears.
5 Press the U or V key to select [Menu Map], [Status
Page] or [Font List].
Sys. Menu/Count.:
a
b
*********************
2
Counter
3
System
[ Exit ]
1
Report
Report:
a
b
*********************
2
Admin Rpt Set.
3
Result Rpt Set.
[ Exit ]
1
Report Print
Report Print:
a
b
*********************
2
Status Page
3
Font List
[ Exit ]
1
Menu Map
