8
8-93
Default Setting (System Menu)
Printing Reports/Sending Notice
Print reports to check the machine settings and status. Default settings for printing the result reports can also be
configured.
NOTE: If user login administration is enabled, you can only print by logging in with administrator privileges.
Printing Reports
Printable reports are as follows.
Menu map
Outputs a menu map of this machine.
Status Page
Check the information including current settings, available memory space, and optional equipment installed.
Menu Map
Status Page
Firmware Version
