67
3
Clean the document scanning area in
the automatic document feeder with the
glass cleaner.
(1) Open the scanning area cover on the
automatic document feeder.
Push in the release switch to release the cover.
(2) Clean the scanning area in the automatic
document feeder.
(3) Close the cover.
4
Replace the glass cleaner.
