84
FAXING THIN ORIGINALS (Slow Scan Mode)
Use this function when you wish to scan thin originals using the automatic document feeder. This function helps prevent
thin originals from misfeeding.
1
Insert the originals face up in the
document feeder tray.
Adjust the document guides slowly.
If the originals are inserted with too much force, they may crumple and misfeed.
2
Select slow scan mode.
(1) Touch the [Special Modes] key.
☞ SPECIAL MODES (page 60)
(2) Touch the [Slow Scan Mode] key so that it is
highlighted.
(3) Touch the [OK] key.
D
C
B
A
D
C
B
A
1
2
Fax/Special Modes
OK
Card Shot
Slow Scan
Mode
Dual Page
Scan
Quick File
Mixed Size
Original
Erase
File
Job
Build
2in1
Program
Timer
(3)(2)
