Touch the [OK] key.
The [Add 'Reply to' to Cc] checkbox can be selected to send a Cc copy to the sender.
When storing pre-set text for the subject and file name in the Web pages, up to 80 characters can be entered.
• System Settings (Administrator): The Number of File Name/Subject/Body Keys Displayed Setting
The setting for the number of subject keys and file name keys displayed in one screen can be changed to 6, 12, or 18.
• System Settings: Default Sender Set
This is used to store the sender name and e-mail address that is used when a sender is not selected.
Sub: Schedule coordination meeting
Material for planning meeting
AAA AAA
Thank you for your continuous support. We have attached sca
Send Settings
OK
Subject
File Name
Reply-To
Body Text
Add 'Reply to' to Cc
