[4] Address Mark [Setup/Reset, Search-Forward/Backward, All Reset] is added

-> See page 5-22.

Address Mark Setup/Reset, Search-Forward/Backward, All Reset] is added to the tool bar and the [Edit]

menu on the [Program Ladder] window and the [Program/Mnemonic] window.

Further, [Jump]-[Go to Address Mark] on the [Edit] menu is upgraded in function.

● Tool bar (for Ladder window)

● Edit menu (for Ladder window)

1 2 3 4

No.6/16

Toolbar

Additional

function

Upgraded

function

Setup/Reset

Search-Forward

Search-Backward

Jump

All Reset

You can set or reset address mark from the edit menu

or tool bar as well as by double-click.

You can search for address mark in forward or

backward direction, just the same way as search

function. (File 8 – 9 can also be searched.)

You can jump to the address mark for file 9 from file 8.

All address marks are reset.
