46
ADDING A COVER SHEET/MESSAGE TO
A FAX TRANSMISSION
This function automatically attaches an 8-1/2" x 11" (A4) cover sheet to your fax transmissions. The cover sheet
shows the date and time, the destination name, the sender's name and fax number, and the number of pages in the
transmission. A message can also be added to a transmission. One of the following messages can be selected:
"CONFIDENTIAL", "PLEASE DISTRIBUTE", "URGENT", "PLEASE CALL BACK", "IMPORTANT".
Selecting a cover sheet / message
1
In Fax mode, press the [SPECIAL
FUNCTION] key.
When the [SPECIAL
FUNCTION] key is pressed, the
special function menu appears.
(To select fax mode, see step 1
on page 20.)
2
Select "COVER SHEET/MSG" with the
[ ] or [ ] key.
3
Press the [OK] key.
4
To add a cover sheet, select "COVER
SHEET" with the [ ] or [ ] key. To
add a message, select the desired
message with the [ ] or [ ] key.
If you do not wish to add a cover sheet, select "NO
CVR. SHEET".
If you do not wish to add a message, select "NO
MESSAGE".
5
Press the [OK] key.
Your machine The receiving machine
Cover sheet / no message Cover sheet / message
No cover sheet / message
Select a cover sheet /
message and
transmit the fax.
A cover is automatically
added and the fax is printed.
The selected message is
printed at the top of the cover
sheet.
The selected message is
printed at the top of the
first sheet.
• Select this function before each transmission. The selection is only effective for one transmission. After one
transmission, the function automatically turns off.
• Before adding a cover sheet, make sure that your sender's name and number have been programmed. (See
"OWN PASSCODE SET" on page 99.)
• This function cannot be used when performing a manual transmission, or when using memory polling (page
41), F-code memory polling (page 52), F-code confidential transmission (page 57), or F-code relay request
transmission (page 61).
• You can also enable a setting in the key operator programs to always add a cover sheet to transmissions (see
"AUTO COVER SHEET" on page 105).
DATE
T O
FROM
FAX #
PAGES
:
MAY-11-2004 TUE 07:30 PM
: SERVICE CENTER
: SBC CO.
: 0666211221
: 02PAGES WERE SENT
(INCLUDING THIS PAGE)
AUTOMATIC COVER SHEET
DATE
T O
FROM
FAX #
PAGES
:
MAY-11-2004 TUE 07:30 PM
: SERVICE CENTER
: SBC CO.
: 0666211221
: 02PAGES WERE SENT
(INCLUDING THIS PAGE)
IMPORTANT
AUTOMATIC COVER SHEET
IMPORTANT
Note
DUPLEX
SPECIAL FUNCTION
ACC.
DUPLEX SCAN
DUPLEX SCAN
GHI
PQRS
T DUPLEX
OK
BACK
SPECIAL FUNCTION
TIMER MODE
POLLING/SUB ADD
COVER SHEET/MSG
COVER SHEET/MSG
NO MESSAGE
CONFIDENTIAL
PLEASE DISTRIBUTE
COVER SHEET
To cancel the cover sheet selection, press the key instead of the [OK] key in step 3.
Note
