SENDING A FAX

BASIC PROCEDURE FOR SENDING FAXES

Make sure that the machine is in fax

mode.

The FAX indicator is lit when the

machine is in fax mode. If the

indicator is not lit, press the

[FAX] key. If auditing mode has

been enabled for the fax function

in the key operator programs, a

message will appear prompting you to enter your

account number when you switch to fax mode. Enter

your account number (5 digits) with the numeric keys.

(See "ACCOUNT CONTROL" on page 100.)

Place the original(s) in the document

feeder tray or on the document glass.

• Using the SPF: page 15

• Using the document glass: page 15

If you are using the document glass to send

multiple pages, place the first page first.

Check the original size. If the original

is not a standard size or the size was

not detected correctly, press the

[ORIGINAL SIZE] key.

When the [ORIGINAL SIZE] key is pressed, the size

selection screen appears. See "MANUALLY SETTING

THE SCANNING SIZE" (page 16) to set the original

size.

If needed, adjust the resolution and

exposure settings. (Page 17)

To adjust the resolution and exposure settings, press

the [RESOLUTION] key. (See "SELECTING

RESOLUTION AND EXPOSURE SETTINGS" on

page 17.)

Dial the fax number.

• The entered number appears in the message

display. Up to 50 digits can be entered. If you make

a mistake, press the [C] key and then enter the

correct number.

• Redialing and automatic dialing can also be used

(pages 18, 22).

Entering a pause

If a pause is necessary when

dialing out from a PBX or when

dialing an international number,

press the [REDIAL] key. (This

key functions as a pause key

when entering a number.)

If you press the [PAUSE] key once, a hyphen ("-")

appears and a 2-second pause* is inserted.

After entering a number, you can also press the

[PAUSE] key to enter a hyphen and then enter another

number using the numeric keys or a Rapid key. (This

connects the numbers together, and is called Chain

dialing.)

* The duration of each pause can be changed in the

key operator programs. (See "PAUSE TIME" on

page 98.)

You cannot place originals both in the SPF

and on the document glass and send them

in a single fax transmission.

COPY

LINE

DATA

SCAN

FAX

EXP

SCAN

FAX

COL

Note

AUTO %

OUTPUT DUPLEX

SPEC

ESS FORMAT

ORIGINAL SIZE DUPLEX SCAN

DUPLEX SCAN

ORIGINAL SIZE

ESS

BROADCAST

ORIGINAL SIZE

AUTO

11x17

8 x14

INCH

COPY

EXPOSURE

PAPER ZOOM

AUTO

SCAN

FAX

COLOR MODE

PROGRAM

RESOLUTION

ADDRESS FORM

ADDRESS

BROADC

RESOLUTION

STANDARD

FINE

SUPER FINE

AUTO

Group keys cannot be used for chain

dialing.

ABC DEF

JKLGHI MNO

TUVPQRS WXYZ

@.-

FUNCTION

ACC. #-C

READ-END

Stand-by. 100%

:0123456789

MEMORY AUTO

CONT 8 x11R

STANDARD

AUTO

46 47 48 49 50

U V W XYZ

SPEAKER

SHIFT

REDIAL/PAUSE SPEED

SYMBOL

COMM

Note
