PERIPHERAL DEVICE TRAYS
This section explains the large capacity trays and the large capacity tray.
TRAY LOCATIONS AND NAMES
The trays are identified by the names indicated below. For detailed information on the sizes and types of paper that can
be loaded in each tray of the machine, see the specifications in the Safety Guide and "PAPER TRAY SETTINGS" (page
77).
When the large capacity trays and multi bypass tray are installed
When the large capacity tray and multi bypass tray are installed
Bypass tray
Tray 5
Tray 6
Tray 7
Bypass tray
Tray 5
