57
CONVENIENT PRINTER FUNCTIONS
USING TWO MACHINES TO PRINT A LARGE PRINT
JOB (Tandem Print)
Two machines are required to use this function.
Tandem Print allows you to divide a large print job
between two machines connected to your network.
The machines simultaneously print each half of the job,
making it possible to shorten the printing time when
printing a large number of sets.
(1) Click the [Advanced] tab.
(2) Select the [Tandem Print] checkbox .
Mac OS X
(This function cannot be used in Mac OS X v10.1.5.)
(1) Select [Printer Features].
(2) Select [Advanced].
(3) Select the [Tandem Print] checkbox .
System Settings (Administrator):
Tandem Connection Setting
Use this to set the IP address and port number of the
slave machine to be used for tandem printing.
Example:
Printing 4 sets of copies
2 sets of
copies
2 sets of
copies
Windows
(1) (2)
The tandem print function does not support SSL
(encrypted communication) between the master
machine and slave machine.
Macintosh
(3) (1) (2)
The tandem print function does not support SSL
(encrypted communication) between the master
machine and slave machine.
