ORIGINAL SIZES

TRANSMITTABLE ORIGINAL SIZES

The following original sizes can be transmitted

* A long original can be transmitted. (The original will be scanned in Mono2.)

THE SIZE OF THE PLACED ORIGINAL

When a standard size original is placed, the original size is automatically detected and displayed in "Scan" in the base

screen.

When the automatic original detection function is operating and the original is a non-standard size, the closest standard

size may be displayed or the original size may not appear. In this event, manually set the correct original size.

☞ Specifying the original scan size (by paper size) (page 71)

Specifying the original scan size (by numerical values) (page 72)

Standard Sizes

Standard sizes are sizes that the machine can automatically detect. The standard sizes are set in "Original Size

Detector Setting" in the system settings (administrator). The factory default setting is "Inch-1".

List of original size detector settings

Minimum original size Maximum original size

Using the automatic document feeder 5-1/8" (height) x 5-1/2" (width)

(131 mm (height) x 140 mm (width))

11" (height) x 31-1/2"* (width)

(297 mm (height) x 800 mm* (width))

Using the document glass

–

11" (height) x 17" (width)

(297 mm (height) x 432 mm (width))

Selections

Standard sizes (detected original sizes)

Document glass

Document feeder tray

(automatic document feeder)

Inch-1 11" x 17", 8-1/2" x 14", 8-1/2" x 11", 8-1/2" x 11"R,

5-1/2" x 8-1/2"

11" x 17", 8-1/2"

x 14"

, 8-1/2" x 11", 8-1/2" x 11"R,

5-1/2" x 8-1/2", 5-1/2" x 8-1/2"R, A3, B4, A4, B5, B5R

Inch-2 11" x 17", 8-1/2"

x 13"

(216mm x 330mm

)

8-1/2" x 11", 8-1/2" x 11"R, 5-1/2" x 8-1/2"

11" x 17", 8-1/2" x 13" (216mm x 330mm),

8-1/2" x 11", 8-1/2" x 11"R, 5-1/2" x 8-1/2",

5-1/2" x 8-1/2"R, A3, B4, A4,

B5, B5R

Inch-3 11" x 17", 8-1/2" x 13-2/5" (216mm x 340mm

)

8-1/2" x 11", 8-1/2" x 11"R, 5-1/2" x 8-1/2"

11" x 17", 8-1/2" x 13-2/5" (216mm x 340mm

)

8-1/2" x 11", 8-1/2" x 11"R, 5-1/2" x 8-1/2",

5-1/2" x 8-1/2"R, A3,

B4,

A4,

B5, B5R

AB-1 A3, A4, A4R, A5, B4, B5, B5R A3, A4, A4R, A5, A5R, B4, B5, B5R, 11" x 17",

8-1/2" x 14", 8-1/2" x 11"

AB-2 A3, A4, A4R, A5, B5, B5R,

8-1/2" x 13" (216mm x 330mm)

A3, A4, A4R, A5, A5R, B4, B5, B5R, 11" x 17",

8-1/2" x 11", 8-1/2"

x 13"

(216mm x 330mm

)

AB-3 A3, A4, A4R, A5, B4, 8K, 16K, 16KR

A3, A4, A4R, A5, A5R, B4, B5, B5R, 8K, 16K, 16KR,

11" x 17", 8-1/2" x 11", 8-1/2" x 13" (216mm x 330mm)

AB-4 A3, A4, A4R, A5, B5, B5R,

8-1/2" x 13-2/5" (216mm x 340mm

)

A3, A4, A4R, A5, A5R, B4, B5, B5R, 11" x 17",

8-1/2" x 11", 8-1/2" x 13-2/5" (216mm x 340mm

)
