17
(8) key
Touch this key to specify a destination using a search
number
*
.
* 3-digit number assigned to a destination when it is
stored.
☞ USING A SEARCH NUMBER TO RETRIEVE A
DESTINATION (page 28)
(9) [Resend] key/[Next Address] key
The destinations of the most recent 8 transmissions by
Scan to E-mail, fax and/or Internet fax are stored. Touch
this key to select one of these destinations. When a
destination is selected or entered, this key changes to the
[Next Address] key.
☞ USING THE RESEND FUNCTION (page 33)
RETRIEVING A DESTINATION (page 26)
(10) Image settings
Image settings (original size, exposure, resolution, file
format, and color mode) can be selected.
☞ IMAGE SETTINGS (page 68)
(11) key
This key appears when a special mode or 2-sided
scanning is selected. Touch the key to display the
selected special modes.
☞ Checking what special modes are selected (page 18)
(12) [Special Modes] key
Touch this key to use a special mode.
☞ 4. SPECIAL MODES (page 87)
(13) [File Name] key
Touch this key to enter a file name when storing a file to
USB memory.
☞ ENTERING A FILE NAME (page 47)
(14) [I-Fax Manual Reception] key
Touch this key to receive an Internet fax manually.
☞ RECEIVING INTERNET FAXES MANUALLY (page
149)
(15) [Direct TX] key
Touch this key to send a fax by direct transmission.
When the [Direct TX] key is not highlighted, normal
transmission (memory TX mode) is selected.
☞ DIRECT TRANSMISSION MODE (page 57)
(16) [Sub Address] key
Touch this key to enter a sub-address and passcode for
F-code transmission.
☞ F-CODE DIALING (page 131)
(17) [Speaker] key/[Pause] key/[Space] key
Touch this key to dial using the speaker.
When entering a fax number to be dialed, the key
changes to the [Pause] key. When entering a
sub-address, the key changes to the [Space] key.
☞ TRANSMISSION USING THE SPEAKER (page 59)
(18) key
When "Hold Setting for Received Data Print" is enabled,
this appears when a fax has been received. Touch this
key to open a password entry screen. Enter the set
password to print the received fax.
☞ PRINTING A PASSWORD-PROTECTED FAX (Hold
Setting For Received Data Print) (page 152)
(19) This shows the currently selected fax reception
mode and the amount of free memory remaining.
☞ RECEIVING FAXES (page 150)
