Acquisition Interface

CS 9300 System User Guide (SM748)_Ed 01 3–3

5 Generator Cooling indicator: Indicates the automatic cooling time (mm:ss) required for the

generator to reach 0 for a new acquisition.

6 Stop button: Stops the unit rotative arm movement

7 Ready Indicator LED

 Green indicates the unit is ready to start acquisition.

 Black indicates the unit is not ready to start acquisition.

8 X-Ray Emission indicator: Yellow, indicates the x-ray emission status.

9 Exit button: Closes the Acquisition interface.

10 Selector Button: Selects different acquisition setting options.

 Click Program to select examination type options.

 Click Patient to select patient type parameters.

 Click Parameters to select exposure parameter options.
