3. Sending

Documents

Removing a document from the feeder

Important!

Do not try to remove a document without opening the operation panel.

This may damage the feeder mechanism.

Open the operation panel by grasping

the finger hold and pulling up.

If you need to remove a

document from the feeder,

open the operation panel.

Remove the document.

Close the operation panel, making

sure it clicks into place.

Click!
