Option Settings
117
8. Option
Settings
Setting 7: DIAL MODE
This sets the mode of dialling. Press 1 if you are on a tone dial line, or 2 if
you are on a pulse dial line.
♦ Initial setting: 1
PSEUDO RING DUR.
or
1 2
TONE PULSE
STOP
DIAL MODE
4
until
display
shows:
FUNCTION
Press
Setting 6: TRANSACTION REPORT PRINT SELECT
TThis sets the condition for printing out a Transaction Report. Enter a
number from 1 to 5 as follows:
♦ Initial setting: 5
1 (ALWAYS PRINT): A report will be printed after each transmission,
reception, or error.
2 (ERR/TIMER/MEM): A report will be printed after an error, timer
operation, or memory operation.
3 (SEND ONLY): A report will be printed only after a transmission.
4 (NEVER PRINT): A report will never be printed.
5 (ERROR ONLY):
A report will be printed only after an error occurs.
TRANSACTION LIST
DIAL MODE
4
until
display
shows:
STOP
FUNCTION
Press
Enter a number
from 1 to 5
Note: For all units installed in New Zealand, select "1" for tone dialling.
The pulse setting "2" will not operate correctly and must not be used.
