Enlarging Part of the Image (E-Zoom)

This is useful when you want to expand images to see them in greater

detail, such as graphs and tables.

Start E-Zoom.

Press the [

z] button to display the Cross ( ).

Remote control

Move the Cross ( ) to the area of the image that you want to

enlarge.

Remote control

When any pair of adjacent [ ], [ ], [ ], or [ ] buttons are

pressed at the same time, the pointer can be moved diagonally.

Enlarge.

Remote control

[z] button: Expands the area each time

it is pressed. You can expand quickly by

holding the button down.

[x] button: Reduces images that have

been enlarged.

[Esc] button: Cancels E-Zoom.

• The enlargement ratio appears on the screen. The selected

area can be enlarged to between 1 to 4 times in 25

incremental steps.

• During enlarged projection, press the [

], [ ], [ ], and

[

] buttons to scroll the image.

Projection Functions
