Adjusting the pen operation area

When using the Easy Interactive Function by connecting to a computer, the

pen operation area is automatically adjusted if the resolution of the

computer changes. You do not need to perform pen alignment again.

You can turn this function On or Off in Auto Adjust Pen Area from

the configuration menu. The default setting is On.

Extended - Easy Interactive Function - Advanced p.103

If you notice the Easy Interactive Pen is out of position even when Auto

Adjust Pen Area is set to On, you can try Manual Adj. Pen Area.

s "Manual Adj. Pen Area" p.66

Manual Adj. Pen Area

Select Manual Adj. Pen Area for Easy Interactive Function from

the configuration menu.

• Adjust to fit the projected image within the screen.

• Display the computer's desktop screen so that you can check

the position of the mouse pointer easily.

Use the [ ] button on the remote control to select "Yes".

The mouse pointer moves towards the top left.

When the mouse pointer stops at the top left, touch the tip of the

mouse pointer with the Easy Interactive Pen.

The mouse pointer moves towards the bottom right.

When the mouse pointer stops at the bottom right, touch the tip

of the mouse pointer with the Easy Interactive Pen.

Easy Interactive Function (EB-485Wi/EB-480i/EB-475Wi only)
