s "Correcting the Focus" p.50

Select "Yes".

Use the [ ] button on the remote control or control panel to select

"Yes". You cannot select Easy Interactive Pen when performing

operations from the configuration menu.

The pattern image is projected and calibration starts.

Wait until calibration is complete.

Do not obstruct the projected light while the pattern image is being

projected.

• Select [ ] using Easy Interactive Pen on the toolbar and execute

Auto Calibration if the discrepancy is small.

• However, execute Auto Calibration from the remote control or

control panel when you are calibrating the pen for the first time.

• For pen positioning, do not switch between making operations using

the remote control and making operations using the Easy Interactive

Pen.

If Auto Calibration is unsuccessful, try Manual Calibration.

"Manual Calibration" p.60

Manual Calibration

This function allows you to manually calibrate the pen.

Set Extended - Easy Interactive Function to Manual Calibration

from the configuration menu.

Adjust the focus by following the on-screen instructions.

Easy Interactive Function (EB-485Wi/EB-480i/EB-475Wi only)
