Other Fax Transmission Settings

1 Make sure that the date and time

display of fax mode appears (if needed

press ) and then press .

2 Press .

3 Press .

4 Select the resolution setting:

: STANDARD

: FINE

: SUPER FINE

5 Press repeatedly to exit.

FAX

Default resolution for faxing

The default resolution for faxing is initially set to STANDARD. If desired, you

can change the default resolution to FINE or SUPER FINE.

1: AUTO RECALL

Display:

FAX SETTING

The display briefly shows

your selection, then:

3: LINE MONITOR
