Setting the Date and Time

5 Enter a two-digit number for the day (“01” to “31”).

Example: the 5

6 Enter the year (four digits).

Example: 2005

7 Enter a two-digit number for the hour (“01” to “12”) and a two-digit

number for the minute (“00” to “59”).

Example: 9:25

8 Press to select A.M. or to select P.M.

9 Press to start the clock.

10 Press repeatedly to exit.

ENTER

TIME 09:25 AM

2: DAY LIGHT SAVE

The currently set time

appears (example):

TIME 12:00 AM

DATE 02-05-2005
