General Machine Settings

1. Installation

Key tone off

The machine normally sounds a beep (key tone) each time you press a key on

the operation panel. If you wish to turn off the key tone, follow the steps below.

1 Press (or ) and then .

2 Press .

3 Press to turn on the key tone or

to turn off the key tone.

4 Press repeatedly to exit.

COPY

SCAN

The display briefly shows

your selection, then:

1: ON, 2: OFF

Display:

COMMON SETTING

4: LANGUAGE
