IBX-530B-270 Embedded System

Page 98

Step 9: When the driver installation is complete, the screen in Figure 6-22 appears.

Figure 6-22: LAN Driver Installation Complete

6.6 Wireless Driver (IBX-530BW Only)

To install the wireless driver, please follow the steps below.

Step 1: Select Wireless from the driver CD list.

Step 2: A new window opens (

Figure 6-23). Select an OS folder. Double click the

Setup.exe to install the LAN driver.
