ForThinkPadEdge15"andE50:

ForThinkPadEdge14"andE40:

Applyinglabelstothebasecover

ThenewbasecoverFRUisshippedwithakitcontaininglabelsofseveralkinds.

IftheWindowsCerticateofAuthenticationlabel(COA)

3isattachedtoapartthatisreplaced,returnthe

oldpartwiththelabelattachedtothecustomer,orprovidealettertothecustomerstatingwhatthelabel

wasoriginallyonthesystemandwhatthelabelpartnumber,serialnumber,andproductkeywere.

Whenyoureplacethebasecover,applythefollowinglabels:

Batterywordlabel

Homologationlabel

92HardwareMaintenanceManual
